Astral XC 100 Benefits
Compact design with increased filtration capacity. The XC 100 maintains the compact footprint of the XC range while offering increased filter area compared to the XC 50 and XC 75. This makes it well suited to medium-sized residential pools needing stronger filtration performance without requiring a large equipment footprint.
No backwashing means major water savings. Traditional media filters can waste thousands of litres of water during backwashing. The XC 100 uses a cartridge-based system that requires only minimal water for cartridge cleaning, making it ideal for environmentally conscious pool owners and water-restricted areas.
Patented Cyclonic Water Filtration technology. The XC range uses AstralPool’s patented cyclonic filtration system to separate contaminants more efficiently before they reach the cartridge element. This helps reduce system pressure, improve filtration performance, and extend cartridge life.
Simple maintenance and fast servicing. The XC 100 is designed for easy cartridge access and straightforward maintenance. Its self-locking ring system helps prevent overtightening while making servicing quicker and safer.
Environmentally friendly pool filtration. By reducing water waste and minimising maintenance requirements, the XC 100 provides a more sustainable filtration solution for residential pool systems.
Australian designed and manufactured. Built for Australian conditions, the XC range combines durable construction, efficient filtration performance, and practical servicing features for long-term residential use.
Astral XC 100 Specifications
| Filter Model | Filter Area | Max. Flow Rate | Max. Flow Rate | 4 Hr Turn Over | 6 Hr Turn Over | Max. Working Pressure | Pump Size | Flow Rate |
|---|---|---|---|---|---|---|---|---|
| XC50 | 4.7 m² | 225 L/min | 13,500 L/hr | 54,000 L | 81,000 L | 250 kPa | 550-750 W | 335 lpm |
| XC75 | 7.0 m² | 290 L/min | 17,400 L/hr | 69,600 L | 104,400 L | 250 kPa | 550-1100 W | 400 lpm |
| XC100 | 9.3 m² | 375 L/min | 22,500 L/hr | 90,000 L | 135,000 L | 250 kPa | 750-1100 W | 410 lpm |
| XC150C | 14.0 m² | 445 L/min | 26,700 L/hr | 106,800 L | 160,200 L | 250 kPa | 750-1500 W | 410 lpm |
| XC150 | 14.0 m² | 445 L/min | 26,700 L/hr | 106,800 L | 160,200 L | 250 kPa | 750-1500 W | 410 lpm |
| XC200 | 18.6 m² | 490 L/min | 29,400 L/hr | 117,600 L | 176,400 L | 250 kPa | 750-1500 W | 405 lpm |
| XC250 | 23.2 m² | 515 L/min | 30,900 L/hr | 123,600 L | 185,400 L | 250 kPa | 750-1500 W | 460 lpm |
Who It’s For
The XC 100 is a great fit if you:
- Want a compact cartridge filter with increased filtration area
- Have limited equipment space around your pool system
- Want to reduce water waste during maintenance
- Prefer a filtration system without backwashing
- Have a medium-sized residential pool or spa
- Want a low-maintenance filtration setup
You may want to consider a larger XC model if:
- Your pool has very high circulation demands
- You operate a larger residential pool system
- Your installer recommends additional filtration area or higher flow capacity
Astral XC 100 Compatibility & Requirements
- Pool type: Residential in-ground pools and spas
- Suitable applications: Residential pool and spa cartridge filtration systems
- Compatible pumps: Single speed and variable speed pool pumps
- Compatible pump ranges: AstralPool E-Series, CTX, and Viron pump ranges
- Compatible sanitising systems: Salt chlorinators, mineral systems, and standard chlorination systems
- Compatible plumbing: Standard residential pool plumbing configurations
- Compatible installations: Compact equipment areas and water-restricted installations
The XC 100 is designed for residential pool systems where compact installation, efficient water filtration, and low-maintenance operation are priorities. For best performance, the filter should be correctly matched with the pool pump flow rate, pool volume, and overall circulation system by a qualified pool technician.
Installation & Maintenance
The Astral XC 100 should be installed by a qualified pool technician following Australian plumbing and filtration standards. Its compact footprint makes it suitable for installations where equipment space is limited while still providing strong filtration capacity.
Routine maintenance involves removing and cleaning the cartridge element as needed. Since the XC 100 does not require backwashing, it significantly reduces water usage compared to traditional media filters.
The self-locking ring system simplifies servicing while helping prevent accidental loosening or overtightening during operation. Regular cartridge cleaning and inspection will help maintain efficient filtration and healthy pool circulation.
